Description
Specifications:
Transmitter
- Frequency Range: 500~970 MHz
- Frequency Stability: ± 10ppm
- Transmitting Power: 10 mW
- Transmitting Distance: 200 m
- Harmonic Power: ＜40 dB
- Modulation: FM
- Function Display: LCD
- Operating Voltage: 3 V, 2 x AA Battery
- Operating Current: ＜130 mA
- Operating Time: 8 hours
Receiver
- Frequency Range: 500~970 MHz
- Oscillation mode: Phase-locked loop control
- Noise control mode: Multiple noise control
- Frequency Stability: ± 10ppm
- Receiving Sensitivity: -105dBm
- Audio Output: Unbalanced 0~200mV/Balanced 0~400 mV
- Output Impedance: 2.2 kΩ
- S/N Ratio: ＞105 dB
- Distortion: ＜0.5%
- Frequency Response: 40 Hz-18 KHz
- Function Display: LCD
- Power Supply: External DC power 12~18 V
Product Features:
- True diversity and four antennas, overcome frequency interruption effectively.
- DPLL digital phase-locked loop multi-channel frequency synthesis technology, provides 200 channel choices, convenient for multiple microphone systems to use at the same time.
- One-key scan function on receiver automatically finds the best available channel,IR sync to easily sync transmitter and receiver in one easy.
- Application: Stage performance, classroom, KTV, conference, family entertainment and outdoor performance.
